超声波清洗+鼓泡冲洗
Ultrasonic cleaning+bubble washing
内槽尺寸：750*1200*500
Inner groove size: 750 * 1200 * 500
内槽容量：451L
Inner tank capacity: 451L
内槽材质：SUS304L
Inner groove material: SUS304L
一、超声波清洗
1、 Ultrasonic cleaning
1、超声波频率：40KHz；超声波功率：0-4800W可调。
1. Ultrasonic frequency: 40KHz; Ultrasonic power: 0-4800W adjustable.
2、清洗加热：6000W；304不锈钢加热管；温度在RT～95℃可调。
2. Cleaning and heating: 6000W; 304 stainless steel heating pipe; The temperature is adjustable from RT to 95 ℃.
3、采用工业级换能器，底部安装震板，方便维修与保养。
3. Industrial transducer is adopted, and shock plate is installed at the bottom, which is convenient for repair and maintenance.
4、电导率检测水质；低液位保护；溢流直排。
4. Conductivity detection of water quality; Low level protection; Direct discharge of overflow.

二、鼓泡冲洗
2、 Bubbling rinse
1、槽体底部装有鼓泡管，连接自有气源。
1. The bottom of the tank is equipped with a bubbling tube, which is connected with its own gas source.
2、配加调压阀门，压力可调。
2. Equipped with pressure regulating valve, the pressure is adjustable.
3、气体搅拌系统上安装电磁阀，并通过控制系统设定时间。
3. A solenoid valve is installed on the gas mixing system and the time is set by the control system.
清洗槽配置过滤循环系统，可实现清洗液体可持续循环利用，降低清洗液体更换频次，节省清洗成本。
The cleaning tank is equipped with a filtration circulation system, which can realize the sustainable recycling of cleaning liquid, reduce the frequency of cleaning liquid replacement and save cleaning costs.
第二槽：高压喷淋
The second tank: high-pressure spray
内槽尺寸：750*1200*500MM
Inner slot size: 750 * 1200 * 500MM
内槽容量：450L
Inner tank capacity: 450L
材质：sus304L
Material: sus304L
槽体装有PU喷淋管道，能够实现内部四周对工件进行高压喷淋冲洗，可使超声波清洗过后残留在工件表面的污渍再次冲刷下来。
The tank body is equipped with PU spray pipes, which can realize high-pressure spray washing of the workpiece around the inside, and can wash the stains left on the surface of the workpiece after ultrasonic cleaning again.
2、喷淋压力大于0.5MPA，压力可调节。
2. The spray pressure is greater than 0.5MPA, and the pressure is adjustable.
3、喷淋功能与槽体盖互锁，关闭盖子后喷淋才能正常工作。
3. The spray function is interlocked with the tank cover. The spray can work normally only after the cover is closed.
4、配手动喷枪。
4. Equipped with manual spray gun.
第三槽：风切吹水
The third slot: wind cutting and water blowing
内槽尺寸：750*1200*500MM
Inner slot size: 750 * 1200 * 500MM
内槽容量：450L
Inner tank capacity: 450L
内槽材质：sus304L
Inner groove material: sus304L
1、槽体四周固定风切管，接气体吹水，快速将工件表面的大颗粒水珠吹落。
1. The air cutting pipe is fixed around the tank body and connected with gas to blow water to quickly blow off the large particles of water on the surface of the workpiece.
2、吹风时风管旋转90°吹扫，风切管可调角度。
2. When blowing, the air pipe rotates 90 ° to purge, and the angle of air cutting pipe can be adjusted.
3、配一把手持气枪，可选择手动吹。
3. Equipped with a hand-held air gun, you can choose to blow manually.
三槽半自动超声波清洗机设备手动平移装置：
Manual translation device of three-slot semi-automatic ultrasonic cleaning machine:
组成：气缸+手动移动小车+气路+电磁阀
Composition: air cylinder+manual mobile trolley+air circuit+solenoid valve
采用SUS304不锈钢支架，在支架安装移动小车，带气动升降机构，可以通过很小力手动移动工件位置，使用者操作更方便省力。
SUS304 stainless steel bracket is adopted. A mobile car is installed on the bracket with a pneumatic lifting mechanism. The workpiece position can be moved manually with a small force, which is more convenient and labor-saving for users.
